铝木门窗组框机结构及装置

设备装有四个机头,其左下机头为固定机头,左上、右上、右下为可移动机头,右上和右下机头可随移动横梁左右移动,可方便的根据窗框的规格进行精确调整.横梁移动为手动方式,安全方便.左上和右上可通过电动葫芦来调节.
The equipment is equipped with four head, the left head is fixed on the head, left, right, right to the movable head, right upper and lower right head can move along with the moving beam, can be conveniently according to the specifications of the window frame adjust the moving beam. For the manual mode, the upper left and right is safe and convenient. Can be adjusted by electric hoist.
右上和左上机头装有速差防坠器,在缓慢升降时,速差防坠器连接绳可随机头缓慢移动,如果机头急速下降时,速差防坠器工作,从而保护设备和操作人员的安全.

The upper right and left upper part is equipped with speed difference anti falling device. When slow rising and falling, the speed difference anti dropping connector rope can move slowly with random head. If the head goes down rapidly, the speed difference anti falling device works, so as to protect the safety of the equipment and operators.

铝木门窗组框机主要结构
The main structure of the frame machine for aluminum and wood doors and windows
该机由四个机头、床身、液压系统、传动系统、电气箱等主要部分组成.
The machine consists of four main parts, such as head, bed, hydraulic system, transmission system, electric box and so on.
铝木门窗组框机安装与保管
Installation and storage of the frame machine for aluminum and wood doors and windows
机床运到用户使用地点,如无运输损伤,即可使用搬运工具将机床移至安装位置.
If the machine is transported to the user's place of use, if there is no transportation damage, the machine can be moved to the installation position using a handling tool.
1、机床应安装在无腐蚀性气体有坚硬平坦的混凝土地面的厂房内.将机床床身下的调平底座支好,机床调至水平,紧固调整螺丝的锁紧螺母,即完成调平工作,可通电通气试机.
1, the machine tool should be installed in the workshop with no corrosive gas and hard and flat concrete floor. The leveling base under the machine bed is supported, the machine tool is adjusted to the horizontal level, the fastening nut of fastening screw is adjusted, that is, the leveling work is completed, and the ventilating test machine is available.
2、接电:三相四线 380V 50Hz
2, connection: three phase four line 380V 50Hz
3、接地:
3. Earthing:
机床床身必须接地,接地线采用黄绿双色多股绞合软铜体(绝缘体),其截面积为2.5平方毫米,接地后机身与主接地点之间的电阻应小于0.1欧姆.
The machine tool bed must be grounded, and the grounding wire is yellow green, double colored, multi stranded, soft copper body (insulator). The sectional area is 2.5 mm2. The resistance between the fuselage and the main grounding point after grounding is less than 0.1 ohms.
4、接气
4, air
工作气压0.5-0.8MPa.把气源接在气源处理器的接头上,检查气动系统有无漏气现象.
The working pressure 0.5-0.8MPa. connects the gas source to the joint of the gas source processor to check the air leakage of the pneumatic system.
