影响铝型材切割机生产精度的因素

2018-03-21 点击数:1568
铝型材的形状各不相同,我们在切割时摆放的方式也不一样,所以这与操作工人的技术与经验有直接关系
The shape of the aluminum profile is different, and the way we put it in the cutting is different, so it has a direct relationship with the workers' technology and experience.
所放材料的数量不一,当切一根与多根时,肯定是前者精度更高是,因为多根切割时,如果没有拿紧或是捆紧,导致打滑,这样在切割时就会影响切割精度
The number of materials placed is different. When cutting one or more roots, it must be the former. The accuracy is even higher. Because when multiple cutting is carried out, if it is not tightened or tied, it will cause skidding, which will affect the cutting accuracy when cutting.
铝材的形状多样,规则的切割精度更高,而不规则的由于不与机台以及刻度尺紧密结合,在测量时会有误差,同时也就导致切割有误差

Aluminum shapes are various, and regular cutting accuracy is higher. Irregular, because they are not tightly integrated with machine and scale, there will be errors when measuring, and at the same time, there will be errors in cutting.

移门生产设备

锯片的选择与所切材料不匹配,切割材料的厚及宽度是选择锯片的关键所在
The choice of the saw blade is not matched with the cut material. The thickness and width of the cutting material is the key to the selection of the saw blade
锯切的速度不一,锯片的转速一般是固定的,而材料的厚薄各不相同,所受的阻力也不一,从而也会让铝材切割机在切割时锯齿在单位时间内里锯的面积也不一样,那自然切割出来的效果也是不一样的
Sawing speed, rotating speed of the saw blade is fixed, and the thickness of the material is different, the resistance is not one, which will make aluminum cutting machine in cutting tooth in unit time inside the area saw that nature is not the same, cutting out the effect is not the same
气压的稳定性,有的厂家所使用的气泵功率是否达到该设备的用气需求,使用该气泵是供几个设备来使用的。如气压不稳定,切割端面会有明显的切痕和尺寸不精准
The stability of the air pressure, the gas pump power used by some manufacturers to meet the requirements of the equipment, the use of the gas pump is for several equipment to use. If the pressure is unstable, the cutting end will have obvious cuts and inaccurate dimensions.
喷雾冷却液是否开启及量充足(需要操作人员每日工作前的观察)
Whether the spray coolant is open and sufficient (requiring the operator to observe the daily work)
操作工人对工作的态度及人员情绪;这应该不难理解,态度是指每一个人对自己所在岗位的价值的认识及自己所应有的责任感(如计时拿工资以几件拿工资的人态度是最能体现的方面)。人员情绪,这是每一个都会存在的事,区别只是在于处理情绪的方法,情绪也会导致一个人对待工作的态度有很大的影响
It's not difficult to understand workers' attitude towards work and people's mood. Attitude refers to everyone's understanding of their position's value and their responsibility. People's mood is a matter of every existence. The difference is just the way to deal with emotions, and emotions can also lead to a great influence on one's attitude towards work.
