铝合金门窗组角机油路需要检查的事项

1将机体后盖打开，油箱的油面应保持在油标的中心线以上，以防油泵吸空，加油时应用120目过滤网滤去新油中的杂质。
1, open the rear lid of the body. The oil surface of the tank should be kept above the centerline of the oil mark, so as to prevent the oil pump from emptied. When using oil, 120 mesh filter is used to filter the impurities in the new oil.
2调试：当安装完毕后，要针对某型材做如下顺序调整。
2 debugging: when the installation is finished, the following sequence adjustment should be made for a profile.
3将溢流阀松开，按下液压启动按钮，观察电机旋向（从上方观察电机应顺时针方向旋转）。将连动开关拨到关位，踩下脚踏阀调整溢流阀，顺时针方向拧动溢流阀调整手轮，系统工作压力提高，反之系统压力降低。
3 release the overflow valve, press the hydraulic start button, observe the motor rotation (from above the motor should be clockwise rotation of the motor). The connecting switch is switched to the shut position, the pedal valve is adjusted, the relief valve is adjusted, the relief valve is adjusted in a clockwise direction, the working wheel is adjusted, and the working pressure of the system is improved, otherwise, the system pressure is reduced.

4将连动开关拨到开位，将控制面板上的定位延时调为2S~3S。退刀延时出厂前已调整好，一般情况下，无须调整。特殊情况下，可打开电器箱，将时间继电器加以调整。

4 switches the switch to the open position and switches the positioning delay on the control panel to 2S~3S. The time delay of the retreating tool has been adjusted before the factory. In general, it is not necessary to adjust. In special cases, the electric box can be opened and the time relay is adjusted.
5将装好角码的型材置于压紧定位块前方，45度接缝处的外角点对准压紧定位块90度内角的顶端。按型材高度调整主定位块高度，使之与型材相适应。组角刀具的高度与型材连接的角码高度相适应，当型材内侧凸筋特殊时应更换主定位块，使之能深入到筋间空腔内，不至于顶到筋上，因此主定位块设计成活连接，以便用户自行按型材配作各种定位块。
Section is tightly positioning block will be installed in front of the 5 corner, the top 45 of the joint angle at the point of 90 degrees angle pressing positioning block. The height of the main block is adjusted according to the height of the profile, so that it can be adapted to the profile. Height and section angle tool connecting bracket corresponds to the height, when the medial rib profiles should replace the main special positioning block, which can go deep into the ribs in the cavity, so as not to the top bar, so the main positioning block design survival connection, so that users with various profiles according to self positioning block.
6主定位块前后位置的调整：踩下脚踏阀使主定位块运行到前极限位置，然后旋转定位缸调整手轮，终使主定位块达“图二”所示位置。
6, the adjustment of the front and rear position of the main positioning block: step on the foot valve to make the main block run to the front limit position, then rotate the positioning cylinder to adjust the handwheel, and finally make the main location block reach the position shown in Figure two.
7压紧定位块的调整：松开压紧螺钉，对压紧定位块高低位置进行调整，使其相对于主定位块之沟槽上下对称。然后对其前后位置进行调整：首先将要组角的型材装上角码，放于主定位块前的定位位置，再松开压紧螺钉，调整压紧定位块的前后位置，终使型材正确定位。完毕后将型材拿出。
The adjustment of the 7 compression positioning block: loosening and pressing the screw, adjusting the position of the pressing position block, so that it is symmetrical to the groove of the main positioning block. And then to adjust its position before and after: first will be installed on the corner section angle, put in the position of the main location in front of the block, then loosen the clamping screw, adjust the pressing positioning block before and after the position, finally make the correct positioning of profile. After the end, the profile is taken out.
8组角刀位置的调整：松开压紧螺钉，使两组角刀的上下位置对称分布于压紧定位块的上下两边，并不超过型材边缘，将螺钉压紧。旋转滑板调整手轮，对组角刀前后位置调整。调整到组角刀的行程时，其位置应达要求。
8 groups of corner cutter position adjustment: loosening the compression screw, so that the upper and lower positions of the two groups of corner knives are symmetrically distributed on the upper and lower sides of the clamping blocks, which do not exceed the edge of the profiles, and screw the screws tightly. The rotary slide plate adjusts the hand wheel and adjusts the position of the corner knife. To adjust the maximum stroke angle knife, its position should be required.
