铝门窗全自动角码锯的相关参数

DJM-450 铝门窗全自动角码锯是济南科莱机器有限公司根据DJM-450 铝门窗全自动角码锯技术为广大的客户设计的理想产品，DJM-450 铝门窗全自动角码锯的产品广泛应用于工业、农业、矿山、交通、建筑、科研、建筑、化工、纺织等各行各业。 ☆该机主要用于铝 门窗角码型材下料

DJM-450 aluminum doors and windows automatic corner saw Ji'nan Kelai machine limited company according to the optimal DJM-450 aluminum doors and windows automatic corner saw ideal technology products for customers to design the majority of the DJM-450 products, aluminum doors and windows automatic corner saws are widely used in industry, agriculture, mining, transportation, construction, scientific research, construction, chemical, textile and other industries. This machine is mainly used for aluminum doors and windows, corner cutting

采用角度可调压紧技术，调整快捷、高效。

Adopts adjustable angle pressing technology, fast and efficient adjustment.

进给运动副采用直线运动轴承，运动阻力小，加工精度高。

The feed motion pair adopts a linear motion bearing, which has small movement resistance and high machining precision.
刀具采用硬质合金锯片，切割速度高，操作方便、安全可靠。
The cutting tool uses the hard alloy saw blade, the cutting speed is high, the operation is convenient, the safety and reliability.
预设切割长度，数字设定切割数量，完成自动停机。
The cut length is preset, the number is set to cut the number of cutting, and the automatic shutdown is completed.
适合铝门窗大批量角码生产的切割。
Suitable for cutting aluminum doors and windows mass production work.
电路系统中安装了电动机相序保护器，提高了系统的安全性。
The electric motor phase sequence protector is installed in the circuit system, which improves the security of the system.
（1）技术参数
(1) technical parameters
切割型面的平面度：0.1mm
Flatness of the cutting surface: 0.1mm
切割型面的垂直度：0.1mm
The perpendicularity of the cutting surface: 0.1mm
切割型面的粗糙度：Ra12.5μm
The roughness of the cutting surface: Ra12.5 mu m
回退速度： 0-3(m/min)
Back speed: 0-3 (m/min)
工进速度：0~3(m/min)
Speed of work: 0~3 (m/min)
动下料长度： 0~150(mm)
The length of moving material: 0~150 (mm)
大加工角码规格：120x120x40(mm)（单边 x 单边 x 厚度）
Large processing angle specifications: 120x120x40 (mm (x) unilateral unilateral x thickness)
输入功率：2.2kw
Input power: 2.2kw
耗气量：200L /min
Gas consumption: 200L /min
主机外形尺寸：1570x995x1545(mm)
Host size: 1570x995x1545 (mm)
电源：380V/50Hz
Power: 380V/50Hz
环境温度：15~40 ℃
Ambient temperature: 15~40 C
气源压力：Air 0.5~0.7(Mpa)
Gas pressure: Air 0.5~0.7 (Mpa)
