玻璃铝条切割的装置结构的组成特点

铝合金门窗加工设备合片机用垂直定位机构托板固定在托板支板上，在托板支板的下面有两个升降缸，升降缸是由升降缸导轴外套升降缸导套构成，托板支板就固定在两升降缸导套上，在两升降缸导套的外壁各铰接有杠杆，杠杆的支点铰接有支板，杠杆的另一端与联动杆铰接，联动杆再与油缸的油缸轴铰接；另外，在托板的一侧还有一个托板定位器。
Aluminum Alloy doors and windows processing equipment assembling machine with vertical positioning mechanism fixed on the support plate plate plate plate, under the support plate with two lifting cylinder, the lifting cylinder is composed of a guide shaft lifting cylinder jacket lifting cylinder guide sleeve which is fixed on the supporting plate plate two lifting cylinder guide sleeve, a lever on the wall two lift cylinder guide sleeve are respectively hinged hinged lever fulcrum, a support plate, the other end of the lever and the linkage rod hinged linkage rod and cylinder shaft is hinged with the cylinder; in addition, the supporting side and a plate positioner.

门窗倾斜问题：门窗在安装完毕后，出现了倾斜、门扇走扇推拉不好的现象，这主要是由于安装人员在安装过程中没有用线坠，靠尺检查门窗与地面或台面的垂直度，造成偏差过大。铝合金门窗加工设备因此安装门窗时，一定要按安装规范去做。门窗不水平：门窗安装后，出现一头高一头低、扇和框的缝隙不均匀现象，有时存在上宽下窄或下宽上窄的问题。处理这种问题，首先要测量窗台或地面的水平度，看一下哪边高，然后以高点为基准，低的地方用木楔或垫块临时固定，以调整窗框的水平度。水平度调好了，窗子就不会出现一边高一边低的现象。

Question: doors and windows in the doors and windows tilted after installation, the door leaf tilt, unable to close properly push and pull bad phenomenon, which is mainly due to the installation personnel did not use wire in the installation process, on foot and ground verticality check doors and windows or table, causing the large deviation. Aluminum alloy doors and windows processing equipment, therefore, when installing doors and windows, must be done according to the installation specifications. The level of windows and doors: doors and windows installed, a large gap appears low, a fan and a frame of uneven, sometimes there are narrow width or narrow width problem. To deal with this problem, we must first measure the window or the ground level, to see which side is high, then the high point for the benchmark, or wedge block temporary fixation with low place, in order to adjust the window level. When the level is adjusted, the window will not appear on the side of the high side of the phenomenon.
托板定位器是在步进电机的出轴上固定一垂直的丝杠，在丝杠上通过螺纹连接一个光电传感器。丝杠采用滚珠丝杠。玻璃铝条切割装置由摆臂、Ａ销轴、夹紧块、固定块、锯片、电机、连接板、Ａ气缸、底板、支架、接头、气缸板、Ｂ气缸、气缸尾座、Ｂ销轴、垫片和电机接头组成。软头快速连接的装置，包括灯罩、与带电线的端子注塑为一体的软头，还包括紧套在灯罩尾端外的塑胶卡套，铝合金门窗加工设备塑胶卡套的外表面上至少有一个凸起点，软头的内表面上有宽度与凸起点相适配的轴向导向槽及与轴向导向槽垂直并相通的止推槽。
The pallet positioner is to fix a vertical lead screw on the shaft of the stepping motor, and a photoelectric sensor is connected on the screw thread through the screw. Ball screw is the best choice for screw. Glass aluminum cutting device comprises a swinging arm, A pin shaft, a clamping block, a fixed block and a saw blade, motor, cylinder, connecting plate, A plate, bracket, joint, cylinder plate, B cylinder, cylinder tailstock, B pin, gasket and motor joint. Quick connecting device of soft head, soft head terminal injection comprises a lamp shade, and charged the line as a whole, also includes a lampshade outside the end of the plastic sleeve, Aluminum Alloy doors and windows processing equipment for plastic sleeve on the outer surface of at least one convex starting point, soft head with an axial guide groove width and convex the starting point is matched with the guide groove and the vertical and axial thrust on the inner surface of groove.
前出装置包括平台、传送辊和支撑轮，平台的两端分别铰接有转板，两转板之间连接有横梁，传送辊设置于横梁上；平台与转板之间设有一组活塞杆、气缸作为转板的驱动机构，活塞杆铰接于平台上，气缸铰接于转板上。敲打门框要用塑锤轻轻地敲，切不可用铁锤去敲。
A device includes a platform, transfer roller and the support wheel, both ends of the platform are respectively articulated with the rotating plate, a cross beam is connected between the two rotary plate, transfer roller is arranged on the beam; a piston rod and the cylinder as the driving mechanism of transfer plate is arranged between the platform and the transfer plate, piston rod hinged hinged on the Yu Ping bench, cylinder turn on the board. Knocking on the door frame should be struck lightly with a plastic hammer, and no hammer can be used to knock it.
