中空玻璃设备生产线程序性能

1、整机全程采用PLC控制设备运转：操作直观方便，变频调速，速度可达32米/分。
1, the whole process of PLC control equipment operation: intuitive and convenient operation, frequency conversion speed, the maximum speed of up to 32 meters / minute.
2、具有W-E玻璃自动识别系统：保证镀膜中空玻璃，（特别是LOW-E玻璃）膜层面不被破坏，清洗段采用特殊防护，三对毛刷全部采用软质高温丝，玻璃输送段装有镀膜玻璃自动识别系统，充分保证镀膜玻璃正确清洗、正确合片。
2, with W-E glass automatic identification system: guarantee film coated hollow glass, (especially LOW-E glass) film layer is not destroyed, cleaning section with special protection, three to the brush all soft high temperature wire, glass section with coated glass automatic identification system, fully ensure the correct cleaning of coated glass, the correct film closing.

3、中空玻璃设备具有三对毛刷，双道清洗：采用三刷三淋，保证清洗干净效果，清洗段全部采用优质不锈钢，与水接触部分采用不锈钢或铜，水箱配有恒温水加热装置，并配有粗、精两极过滤系统。

3, the hollow glass equipment has three pairs of brushes, double cleaning: using three brush and three drenching to ensure the best cleaning effect. All the cleaning sections are made of high quality stainless steel. Stainless steel or copper is used in contact with water. The water tank is equipped with constant temperature water heating device, and it is equipped with a coarse and fine two pole filter system.
4.节能间断式自动工作系统：整机采用节能间断式自动工作系统，当玻璃运行至上料段末端光电传感器时，毛刷、水泵、风机自动启动，节能省电。
4. energy saving intermittent automatic working system: the whole machine adopts energy saving and discontinuous automatic working system. When glass running is the first photoelectric sensor at the end of the material section, the brush, water pump and fan automatically start, saving energy and saving electricity.
5.中空玻璃生产具有定位准确，无错位现象：压片机内，真空发生器采用进口产品，吸力大，吸盘真空度在0.8bar以上，分区域自动吸合玻璃，充分保证吸住玻璃后不会下滑。
5. hollow glass production has accurate positioning, no dislocation: in the press machine, the vacuum generator adopts the imported famous brand products, the suction force is large, the vacuum degree of the suction cup is above 0.8bar, the partition domain automatically sucks the glass, and it is fully guaranteed that the glass will not fall after the glass is sucked.
6.压合精度高：采用液压驱动，运动采用双向直线导轨，后板面有自动导向定位功能，充分保证两个板面平行压合，根据中空玻璃板面的大小，设有调压功能，保压时间根据玻璃大小可调整。
6. high precision: using hydraulic drive, motion using bi-directional linear guide, the rear plate surface has automatic orientation function, fully guarantee the two plate parallel compression, according to the size of the hollow glass plate, pressure regulating function, pressure keeping time can be adjusted according to the size of glass.
