铝木门窗设备的铣削设备种类及使用

一、仿形铣床:仿形铣床用于铝木门窗各类槽孔如排水槽、滑轮槽、锁孔等的仿形铣削加工.根据铝木门窗设备结构特性分为单头仿形铣床和双头仿形铣床.
A copying machine: copying milling machine for profiling milling aluminum wood doors and windows of various types of slots such as drainage groove, pulley groove, etc. according to the structural characteristics of keyhole aluminum and wood doors and windows equipment is divided into single and double copy milling machine copy milling machine.
1.单头仿形铣床:只有一个仿形铣头,一次夹紧完成一处孔槽铣削的仿形铣床
1. single head profiling milling machine: only one profiling milling head, a clamping finish a hole groove milling profiling milling machine
2.双头仿形铣床:有两个仿形铣头,一次夹紧可以实现垂直和水平两个方向的仿形铣床

2. double head profiling milling machine: there are two profiling milling heads, one clamping can realize vertical and horizontal two direction profiling milling machine

二、水槽铣床:水槽铣床是铝木门窗框、扇下边料有排水要求的型材排水槽及型材气压平衡孔铣削加工的专用铝木门窗设备.
Two, the sink sink is a special milling machine milling machine: aluminum door window frame, there are fan under the material requirements of the drainage section water slots and air pressure balance hole profile milling wood doors and windows equipment.
1.按结构分类:单轴水槽铣床;双轴水槽铣床;三轴水槽铣床;四轴水槽铣床.
1. according to the structure classification: single axis water groove milling machine; double axis water trough milling machine; three axis water trough milling machine; four axis water trough milling machine
2.按功能分类:自动水槽铣床;普通水槽铣床.
2. according to the function classification: automatic trough milling machine; ordinary water trough milling machine
三、端面铣床:用于铝木门窗螺接时中梃的端面铣削,通过更换不同刀具,可以铣削不同断面的型材.
Third, end milling machine for face milling stiles aluminum wood doors and windows screwed, through the replacement of different tools, milling can different sectional profiles.
四、封盖铣床:封盖铣床用于铝合金推拉窗封盖的两端与上下滑道配合的封盖槽的铣削,不同的型材系统配以相应的成型刀具与相应导料槽.
Four, capping milling machine: cover milling machine used for aluminum alloy push and pull window cover at both ends of the upper and lower slide with the cover groove milling, different profiles system with the corresponding molding tool and the corresponding guide groove
五、锁孔槽加工机:该机是加工铝木门窗传动器类五金配件安装孔槽的专用铝木门窗设备,一次装夹可完成水平方向三个孔德钻削和垂直方向长圆孔的仿形铣削.
Five, the lock groove processing machine: the machine is used for processing aluminum aluminum and wood doors and windows driver hardware accessories installation hole groove wood doors and windows equipment, a fixture can finish horizontal profile milling three hole drilling and vertical hole.
